Imperial Rib Panel
Imperial Rib Panel Details
Imperial Rib panels are formed from high tensile strength, 29-gauge steel, which is protected with a Galvalume coating. Our state of the art Signature 200 paint system is then applied, providing years of warranted protection for our color coated panels. Refer to our color chart to select any of our many contemporary colors. Imperial Rib is manufactured for your application and is available in cut-to-the-inch lengths.
Imperial Rib Panel Specifications
- 3/4" rib with 36" coverage
- 9" rib spacing with 5 major ribs and 8 minor ribs
- Durable, baked-on paint finish
- Complete line of trim and accessories
- Anti-siphon feature
- Wide variety of beautiful colors
- 29-gauge standard
- Galvanized and Galvalume
Specifications
Colors
Available Parts
SL-16 Panel
SL-16 Panel Details
SL-16 is a sleek contemporary panel system ideal for residential applications.
SL-16 panels are formed from high tensile strength, using 29 & 26 gauge steel, which is protected with a Galvalume coating. Our state of the art Signature 200 paint system is then applied, providing years of warranted protection including Energy Star Compliance, Class A UL Fire Rated, and UL 2218 Class 4 rated for impact resistance. SL-16 is manufactured for your application and is available in cut-to-the-inch lengths and is available in a wide variety of standard colors.
SL-16 Panel Specifications
- Panel Type – Concealed Fastener Metal Panel
- Panel Width Coverage – 16”
- Rib Height – 1”
- Gauges – 29 and 26 gauge
- Metal Panel Substrate – Galvalume
- Paint Finish Type – Siliconized Polyester
Specifications
Colors
Available Parts
PBR Panel
PBR Panel Details
Drip Stop, an internationally patented CCM (Condensation Control Membrane), is pre-applied to the panel in our manufacturing facility and allows the PBR panel the capability to trap and then release moisture back into the air in the form of normal humidity.
PBR with Drip Stop technology is a unique solution for protecting your assets through condensation control while maintaining the aesthetics and structural elements that Infinity Metal Supply proudly offer.
PBR Panel Specifications
- Panel Type: Exposed Fastener Metal Panel
- Panel Width Coverage – 36″
- Rib Height – 1 1/4″
- Gauges – 29 and 26 gauge
- Paint Finish Type – Siliconized Polyester
- Available with Drip Stop condensation control application
Specifications
Colors
Available Parts
Lok Seam
Lok Seam Details
One of the most versatile architectural metal panels available today, LokSeam by Infinity Metal Supply, is a snap-together, concealed fastener, standing seam roof system with a 1 3/4″ tall vertical rib, for use on roofs with a minimum slope of 3:12. Available in 12-inch, 16-inch and 18-inch widths, LokSeam panels can be installed over open framing or a solid substructure and are capable of transitioning from roof to fascia with the use of a rib cover and does not require a solid substructure for support.
Lok Seam Specifications
- Coverage Width – 12″, 16″, 18″
- Minimum Slope – 3:12
- Panel Attachment – Concealed Fastening
- System, Standard and UL90 Clips
- Gauge – 24 (standard)
- Coatings –Signature® 200, Signature® 300, Signature® 300 Metallic
Specifications
Colors
Available Parts
